Forum Index : Microcontroller and PC projects : PicoMiteWeb alphas - It had to be done
  Page 2 of 5   |
|||||
| Author | Message | ||||
| TrevorC Newbie  Joined: 15/07/2020 Location: United KingdomPosts: 14 |
Anyone else getting a Error : Not enough memory message when trying to edit a program after running it. Trying to load another program after the above error also gives the same message. I am also getting multiple ssids as above with wifi scan. PicoMite MMBasic Version 5.07.07a1 OPTION SYSTEM SPI GP18,GP19,GP16 OPTION SYSTEM I2C GP0,GP1 OPTION COLOURCODE ON OPTION LCDPANEL ILI9341, RLANDSCAPE,GP15,GP14,GP13 OPTION TOUCH GP12,GP11 GUI CALIBRATE 0, 376, 297, 888, 663 OPTION WIFI (details removed) OPTION SDCARD GP22 > memory Program: 4K ( 4%) Program (144 lines) 78K (96%) Free RAM: 0K ( 0%) 0 Variables 2K ( 1%) General 112K (99%) Free The program is a analogue clock. Setting the date and time from the internet is useful. Trevor |
||||
| matherp Guru  Joined: 11/12/2012 Location: United KingdomPosts: 9139 |
That's an easy one to fix but I'm making no progress at all on TCP and UDP socket support so it may be some time before I post the next alpha |
||||
| TrevorC Newbie Joined: 15/07/2020 Location: United KingdomPosts: 14 |
Thanks for the reply. Trevor |
||||
| lizby Guru Joined: 17/05/2016 Location: United StatesPosts: 3152 |
I have to say that the prospect of TCP and UDP socket support for the Pico W is very exciting. For me, it would change the Pico from something which has been loads of fun to play with to a device that I will actually use in my household monitoring and control designs. For 15 years or more I have cobbled things together using PICAXE plus various tiny routers running OpenWrt, Raspberry Pi ZWs with Lua, and ESP8266 and ESP32 running Annex. I'd much rather use MMBasic on a Pico W. Looking forward to coming announcements. PicoMite, Armmite F4, SensorKits, MMBasic Hardware, Games, etc. on fruitoftheshed |
||||
homa Guru Joined: 05/11/2021 Location: GermanyPosts: 351 |
matherp i hate  and love  you, what great news!Because of your earlier statements I got myself an ESP-12E module. Now this runs since today and I think great, check thebackshed forum, maybe someone is interested. And now this! Thank you! And keep going ... ;-)  I will test this on the weekend **joy**  Edited 2023-02-02 06:52 by homa |
||||
| homa Guru Joined: 05/11/2021 Location: GermanyPosts: 351 |
okay I could not wait until the weekend :) > Connecting to WiFi... Connected. PicoMiteWeb MMBasic Version 5.07.07a1 Copyright 2011-2023 Geoff Graham Copyright 2016-2023 Peter Mather > web http server open Starting server at 192.168.1.109 on port 80 > when I start the webserver and then access with ncat comes weird stuff? C:\Users\homa>ncat -n 192.168.1.109 80 ¢/í¸┘h¶┘<¿5ÕÅ*═┬@┴¤Rqjr)#░[*éêD↓0‗kú«ä═IÍâB↨þú9ôsãµ±è■!↓õuÄãçàX¦$µØ]D@ïZ#^®´ý?æ£zA↨↑rÙ♠‗毩l¥┘4¸4#♠z3pùÎR↕§~Êöòf♠#Y‗o·þý®µ½¬9┐║_Ñ▒«$üaèxEõ<Gx9GÃØ┘J»a↨;¢j§ðD[æ═_u_A©ı8■ÏZ▒/F╝Ä5*8╠*»»båuUt∟pú Ò_¥│¶z'X'k►Ï▒►Ü«8äÍ çUzúu5┐>qlä'w┴Ð┬Óûe dmt ]ç`ÌÀ]ïä6Ó╗┐ùàó ┴ZH∟╔┼ëiʬ2¤q╚ζQó♠ì↔═Ý╔·╔↑W♣g²ëöÛS¢ D▄Ñ ıúLÄöôí$t═→♦úA ↕OBÿ╦s÷¨T│ÈýÁ▲éVc{`º¬¼ßõ8Mf:▲ÀP¬g8Ó¯ÂfîGâ├d├ )╚o▀x♠©ä◄îü→È-4¬h¼vrüçï+Z/&¥Ìý┐8¡░▀ú ró*L«wÃè┐}┼▼Ã↑D↑ý_f±£j└Ï0MO:►└Í{ax,Ô♣Î,ä╔¬Ï--▒áÔTú═♠☺c‼o►ëDûM´┬d‗┤G×Ç]wâB→↓×↓¨¡NÒ→►U┐êSÅê³►:ŹéSå↕^ 2╝♠È° └¤►È↔5·╬N-↨☺xÃ÷♣î(®ì;¾[¬¾W♦ä¿~s~ÁÐ!]5Ù)P┴X♠´.DÆz↑╗BÂUtÁ è╦ZHè┘c»¶ Iç╗├çëEIÇþ▒ÃY╔Q ëÐ¥Íû‼ÿ_³■Ú!╬¢YoB@┼FHI$qÝs"×↨Û@säû►»á┤àH«Ñj♠↕L§@│ÚWQïsÀã½│╠╗■Î9Qhm╬]áZ÷ð«▓?o╬ o>kï+!▀*a╚;×gçƯ→Ê é¶1ø÷'A5¡Úà▬ÙE´cÐÑáÔ2& Qåêï¾→B«£Àu┼§H┐ÆìY‗sBÁÿ▲îëoYò$├└rq█Q@dXN¥¶▀ÀóåØK┤☻ìÂÊÐ♥ÌW¶┴☻õÃ6rıuºïKM ù╠ä0½▄×ä»;◄a╔èÝ´ôñ╠↔*¢Ò Y→{ÀéÃ♣¹→ÉOéé╩Ö2m┤i#q▬ñ8´1jbï┌¶Ô²♣ú▓║ñ"+ÿf6│Ò¶ñ¬♥^JtË┤░jï♣↨→Ƶ┘ÖªrM£R³YA∟▲äS=BíÛ¸♣↨ƒ╚ß²B½+íÅã×╦(Ý-╠▲°‼┌þ3■qü¹├nòKæj∟æ‼Ñâ?¹│1ý╝ެú®┴ÒH↕C→{P/LuÅ3.²±J) Ë┌I╗Þ´F¢Ú7V&=↓ÀoëNÉ┐¶U[│Û▬NåSn(Õ↓=jö↑┘╣(│i{█ "!õÏ∟A│_³Ó6fBÝ╗÷â>Yè→P¨Ia‼░¬OJ│]╣§k6¥d6èÂâ╝x☺VÁB²ƒÔB¡ðØD^Äd7Àç]*Ê┬╔^┌Þû^┬▒b*°úÚè;─RI?`< ñ▒]×)ñKð ┬²e)z¦N¥n¬ÂÂbÚ»♦7£¬├▬`Z┬'¯┬¤4♥{P±©│▼´¶çX▄ ÐN╬üaWuﶴÈ~ò─ѧkaBc¡Ýª▼▒╔▓pt[ BP*<\þ┼♥6bw├6╝UB↨MQ¨uÜ´¨|Õ→BntX£hE↔»ú}ò¬ ù¯59N╔`xÇ┼±.E│g↕$£^♦©çÖbÐ═↑Ï└ !}m▲K©!U;ZW³×i‼iòWÂ█f‗Ûdw┌┤kKA2↕o│ª¨ò¯☺4╗Ì►ì►▓Áæ■┤gæþ°♦êpè─♦LÙÖ‼I¶b░¨ÈÆÄéÄ3g▒;Aúÿ↕÷↓fIàI■¤o¶╩ô↕╗£ôÑÆöKÀùxpá┘i.→ ¾Ó│☺ÕÔ§s╚ÍïC¦qõ3=║X>qá↔┘┴[ÝÿAîλzÛQ± ☺.΃¤▒┴G¦·¼é╚U«µ─7|╔K¸)ò▄}¿ı♠3¿SéyòºÆ©HOu☺{BamD░,Èk±ýg"►GÙÔZ↓ú╠■õ]©mò% X┼¨╠ÀaÚ█m↔N┴í┐↑Ëd@5↔J ÞíúJ─î▲=fj☻ryb♠╦%¯²½§'ö¢Ôp&Û↓U│Ú╔·¾8á|µQı╠B3W if I call the ip in the browser opens the save as dialog?! in this file is also only grit. do you have any ideas, matherp, about which commands to implement and how? it would be helpful to query the ip assigned via dhcp with a command and or on startup after Connected: <ipadr>. Edited 2023-02-02 07:32 by homa |
||||
led-bloon Senior Member  Joined: 21/12/2014 Location: AustraliaPosts: 205 |
@matherp - Peter Does this code/site help at all? benevpi or picow-http led Edited 2023-02-02 09:33 by led-bloon Miss you George |
||||
| TrevorC Newbie Joined: 15/07/2020 Location: United KingdomPosts: 14 |
Just noticed that Web ntp response prints date and time correctly but the month is not being being updated in date$. Trevor |
||||
| matherp Guru Joined: 11/12/2012 Location: United KingdomPosts: 9139 |
Finally some progress - note the Pi icon at the top left responding to the favicon request  Dim buff%(512) Dim ls%(64) Dim s$=Space$(255) LongString append ls%(),"<!doctype html>" LongString append ls%(),"<HTML>" LongString append ls%(),"<BODY>" LongString append ls%(),"<H1>Hello World!</H1>" LongString append ls%(),"</BODY>" LongString append ls%(),"</HTML>" LongString append ls%(),Chr$(10)+Chr$(13) WEB open tcp server 80 WEB tcp interrupt myint WEB ntp Do 'background processing Loop Sub myint WEB tcp read buff%() If LLen(buff%())=0 Then Exit Sub Local p%=LInStr(buff%(),"GET") Local t%=LInStr(buff%(),"HTTP") If (p%<>0) And (t%<>0) And (t%>p%) Then s$=LGetStr$(buff%(),p%,t%-p%+4) Print "String is ",s$ EndIf If Instr(s$,"favicon") Then Print "sending icon" WEB Transmit FILE "pi.ico","image/vnd.microsoft.icon" Else Print "sending page" WEB tcp send ls%() WEB TCP close EndIf End Sub I'll post a new release when I've got the code that reads an html file in and automatically populates screen fields with the values of MMbasic variables. This is code from the original PiCromite which can finally make a re-appearance  Edited 2023-02-03 01:59 by matherp |
||||
Plasmamac Guru Joined: 31/01/2019 Location: GermanyPosts: 554 |
Great Plasma |
||||
| lizby Guru Joined: 17/05/2016 Location: United StatesPosts: 3152 |
Fabulous. PicoMite, Armmite F4, SensorKits, MMBasic Hardware, Games, etc. on fruitoftheshed |
||||
| Pluto Guru Joined: 09/06/2017 Location: FinlandPosts: 359 |
Dont know what I am going to use it for, but after understanding that Matherp is developing something for Pico W, I immediately ordered a few. No hurry with the development Peter, I have still to wait a couple of weeks for arrival of the W  |
||||
| homa Guru Joined: 05/11/2021 Location: GermanyPosts: 351 |
 hello Peter, i tried running your code with version 5.07.07a1 on my original pi pico w. Unfortunately the setup as in your screenshot does not work for me! Do you have another version? I also have a pi.ico file on the flash drive. Will there also be a way to manage tcp connections yourself? As with the ESP-12E module? There you can manage up to 5 connections. How does that actually look with the pico w? According to Internet data, it can manage up to 4 clients as a SoftAP. Does that mean that up to 4 client accesses to the pico w are feasible? Would it make sense to use the AT commands of the ESP-12E module as a basis for the WEB command? In any case the testing is fun. And I can help you here with pleasure. The attempts 1-6 are actually self-explanatory ... Greetings from rainy Germany Matthias |
||||
TassyJim Guru Joined: 07/08/2011 Location: AustraliaPosts: 6102 |
To quote Peter: You have to wait for the new alpha release for the new example code to run. Jim VK7JH MMedit MMBasic Help |
||||
| homa Guru Joined: 05/11/2021 Location: GermanyPosts: 351 |
The EDGE web browser also has this behavior of wanting to download a file ... but the program behaves differently!  |
||||
| homa Guru Joined: 05/11/2021 Location: GermanyPosts: 351 |
Thanks Jim, I had understood this sentence differently. Matthias |
||||
| homa Guru Joined: 05/11/2021 Location: GermanyPosts: 351 |
Hello Peter, now you've made my mouth water. The wait is getting me down. Is there any news? Or can you say something about my questions? Greetings Matthias |
||||
| matherp Guru Joined: 11/12/2012 Location: United KingdomPosts: 9139 |
||||
| homa Guru Joined: 05/11/2021 Location: GermanyPosts: 351 |
Thanks a lot Peter! @all: Attention- the new version also deletes the flash disk! I just lost the test file from me because of my impatience. Not too bad, but if someone has more on it ... just as a hint! |
||||
| matherp Guru Joined: 11/12/2012 Location: United KingdomPosts: 9139 |
Just noticed the BB has corrupted the html even though it is in a code block test4.zip |
||||
