All, This is version LA_23 with - in 6 channel mode, lower part of the screen is help text - user manual small changes Put banner.bmp and LA_23.bas in one directory, and run LA_23 Suc6 Volhout LA_23.zip PicomiteVGA PETSCII ROBOTS |
||||
| Volhout Guru Joined: 05/03/2018 Location: NetherlandsPosts: 4234 |
All, For those people running PicomIteVGA version 5.0708b7 and later, you can benefit from the improved DMA functionality. This does not add features to the LA, but allows infinite wait times for a trigger. The earlier releases would time out after minutes...hours depending the sample speed. Peter has fixed this in MMBasic. This version makes use of that fix. Volhout LA_24_DMA_autodetect.zip Edited 2023-07-01 03:43 by Volhout PicomiteVGA PETSCII ROBOTS |
||||
| Volhout Guru Joined: 05/03/2018 Location: NetherlandsPosts: 4234 |
Minor update to LA_24. - faster screen writes using framebuffer. Tested on V50800beta5. Screen update from 281ms (252MHz) down to 119ms. - fixed a bug in channel name editor LA_24_1.zip Volhout @Peter: the vertical lines in the trace are disabled for in this version. Uncomment line 649 to get them back. Edited 2024-01-11 01:09 by Volhout PicomiteVGA PETSCII ROBOTS |
||||
